MINERALS PROCESSING
Mineralogy and Surface Chemical Control in Flotation, Leaching and Alumina Processing

The Issues

Losses of value in flotation and leaching have multiple possible causes. Mineralogical interferences and surface chemical control tend to be considered after most other operating variables have been adjusted without benefit. Diagnosis of the interference or variability in mineralogy and/or surface chemistry is required to direct changes in processing.

Problems with mineralogy and surface chemistry resulting in low grade and recovery in concentrates can be in unrecognised fractions of ultrafine particles (< 200 nm), clays and clay aggregates (< 2 µm), amorphous minerals (e.g. silica, talc- and chlorite-like fines that surface-attach more readily than crystalline forms) and in precipitated particles all obscuring value mineral surfaces.

The Complete Strategy

Blue Minerals Consultancy offers a guide to plant metallurgists seeking to improve recovery and/or selectivity in froth flotation and in recovery from leaching and alumina processing where this is limited by mineralogy and surface chemistry.

We provide a strategy for recognition of these limitations, provide advice on strategic analyses, and potential changes to operation suggested by this analysis. A complete analytical strategy has been developed for identification of causes of losses in recovery, grade or kinetics due to mineralogy and mineral surface conditioning. We compare surface chemistry of selected mineral phases from plant samples in flotation between feed, concentrate and tail, in leaching and in alumina processing during the leach or precipitation progress.

Schematic of the strategy.

Use and Potential Improvements

Specialised mineralogical analysis may directly indicate that there are factors unrecognised in standard mine mineralogy and liberation studies (e.g. amorphous minerals, residual thin surface layers) or that there has been a change in the proportion of fine and ultra-fine particles, including clays and silicates, likely to interfere with value mineral surfaces.

In flotation, this approach has been used for plant reagent selection and optimisation (collectors, activators, depressants) by statistical comparison of surface adsorption of different reagents between different minerals.

In leaching, the combined analytical strategy has been used to show that solution species, rather than developing surface layers (as has been assumed), can control leach kinetics suggesting a different processing strategy to improve kinetics. It has also defined residual and altered phases retaining value allowing changes to processing to improve nickel recovery from. 74% to 92%.

In gold processing the same potential exists, as in flotation, for increased recovery and value and/or decreased costs through full identification and statistical analysis of the interfering processes or species, enabling changes to the processing to be correctly targeted and trialled. Analyses and subsequent strategies for correction can be applied to direct comparisons of feeds, in-process and product samples in the overall circuit, to parts of the gold recovery circuit in which losses are known to occur in normal operation, or to troubleshooting changes in recovery.
